Our XPS foam insulation panels stand out for their superior combination of high strength, low weight and excellent insulation performance. Whether you are managing temperature-sensitive cargo or improving the overall efficiency of truck transportation, our insulation panels provide high-performance solutions that meet the highest industry standards.

Panel Advantages

  • High strength-to-weight ratio.
  • Good thermal insulation.
  • Long service life.
  • Good weather resistance.

Application Areas

  • Frozen meat transportation.
  • Cold chain logistics.
  • Pharmaceutical transportation.
  • Fresh produce distribution.
  • Multi-temperature zone temperature-controlled freight.

Specifications

  • Top Facing: CFRT (Continuous Fiber Reinforced Thermoplastic) sheet. (Thickness: 0.7~2.0mm)
  • Core Materials: XPS (Extruded Polystyrene) foam. (Density: 35~50kg/m³)
  • Bottom Facing: CFRT (Continuous Fiber Reinforced Thermoplastic) sheet. (Thickness: 0.7~2.0mm)
  • Width: Max 2.8m.
  • Length: Max 12m.
  • Thickness: 10~150mm.
Category:

Description

Expert in Truck Body Composite Panels

TOPOLO-TRUCK has developed a series of high-quality composite panels for box truck bodies. Our composite panels are designed to perfectly combine strength, quality, aesthetics and environmental protection requirements, which can help you improve the durability, safety and transportation efficiency of your trucks. We use industry-leading materials and technologies to carefully build and provide the best solutions for your vehicle projects, and provide high-quality products that meet strict standards and exceed customer expectations.


Materials and Applications

Core Facing Applications
XPS (Extruded polystyrene) Foam FRP Sheet, CFRT Sheet. Refrigerated Trucks, Dry Freight Trucks.
PU (Polyurethane) Foam FRP Sheet, CFRT Sheet. Refrigerated Trucks
PET (Polyethylene Terephthalate) Foam FRP Sheet, CFRT Sheet, Aluminum Sheet, ACP Panel. Dry Freight Trucks
PVC (Polyvinyl chloride) Foam FRP Sheet, CFRT Sheet, ACP Panel. Refrigerated Trucks, Dry Freight Trucks.
PP (Polypropylene) Honeycomb FRP Sheet, CFRT Sheet. Dry Freight Trucks
HDPE(High-density Polyethylene) Plastic Galvanized Steel Sheet, Aluminum Sheet. Dry Cargo Trailers
Plywood FRP Sheet, CFRT Sheet. Dry Freight Trucks

Note

  • FRP: Fiberglass reinforced.
  • CFRT: Continuous fiber reinforced thermoplastic.
  • ACP: Aluminum Composite Panel.

Composite Panel Production Lines

We have multiple one-piece composite panel production lines that can meet vacuum adhesive composite and thermoplastic composite production. The panel size can be up to 12m long and 3.2m wide.

Vacuum Adhesive Composite Production Line
Thermoplastic Composite Production Line

CNC Machining

The composite panels are processed into designed shapes at high speed and high precision on large CNC processing platforms, and the panels in the same batch can maintain consistent precision.


Accessories Services

Provide standard and non-standard parts to meet special application requirements. Including sheet metal processing, laser welding, aluminum profile processing, metal casting processing, etc.


Truck Body CKD/SKD Services

TOPOLO-TRUCK provides box truck bodies in the form of CKD (Completely Knock Down) and SKD (Semi-Knocked Down), and provides optimized design services.
